Print Head / Ink

Type

Permanent

Number of Nozzles

Total 1,280 nozzles

Ink Cartridges

PG-47, CL-57S
(Optional: CL-57)

Maximum Printing Resolution

4800 (horizontal)^*1 x 1200 (vertical) dpi

Print Speed^*2

Based on ISO/IEC 24734
Click here for Summary Report
Click here for Document Print and Copy Speed Measurement Conditions

Document (ESAT/Simplex)

Approx. 7.7 ipm (black)/4.0 ipm (colour)

Photo (4x6") (PP-201/Borderless)

Approx. 65 sec

Printable Width

Up to 203.2 mm (8")

Printable Area

Borderless Printing^*3

Top/Bottom/Right/Left margin: each 0 mm
(Supported paper size: 4 x 6", 5 x 7", Square (5 x 5")

Bordered Printing

Top margin: 3mm, Bottom margin: 5mm,
Left/Right margin: 3.4 mm (LTR: Left: 6.4 mm, Right: 6.3mm)

Support Media

Rear Tray

Plain Paper
Photo Paper Plus Glossy II (PP-201)
Glossy Photo Paper "Everyday Use" (GP-508)
Photo Paper Plus Glossy II (PP-208)

Paper Size

Rear Tray

A4, A5, B5, LTR, LGL, 4 x 6", 5 x 7", Square (5 x 5")

Custom size:
width 89 - 215.9 mm, length 127 - 676 mm
* F4 is possible via custom size settings.

Paper Size (Borderless)^*4

4 x 6", 5 x 7", Square (5 x 5")

Paper Handling (Maximum Number)

Rear Tray (Plain Paper)

A4 = 60

Paper Weight

Rear Tray

Plain Paper: 64-105 g/m²,
Canon specialty paper: max paper weight: approx. 275 g/m²
(Photo Paper Plus Glossy II, PP-201)

Ink End Sensor

Dot count

Print Head Alignment

Manual

Scanner Type

Flatbed

Scanner Method

Optical Resolution^*6

600 x 1200 dpi

Scanning Bit Depth (Input/Output)

Grayscale

16 bit/8 bit

Colour

RGB each 16 bit/8 bit

Line Scanning Speed^*7

Grayscale

1.5 ms/line (300 dpi)

Colour

3.5 ms/line (300 dpi)

Maximum Document Size

Flatbed

A4/LTR (216 x 297 mm)
